Incorporating an 8-inch MMP II bass driver with Monitor Audio’s signature C-CAM Gold Dome tweeter to provide high performance sound, ease-of-drive, and wide frequency response and dispersion.
Optimum imaging and set-up are established via a pivoting tweeter and high-frequency (+3 dB / 0 dB /-3 dB) level adjustment.
Optional square grilles can be used with this model.
Specification:
- Frequency Response: 50 Hz – 25 kHz
- Nominal Impedance: 6 ohms
- Sensitivity (1W@1M): 90 dB
- Maximum SPL: 111.6 dBA
- Power Handling (RMS): 120 W
- Recommended Amplifier Requirements: 30 – 120 W
- Drive Unit Complement:
- 8" MMP II cone bass driver
- 1" C-CAM pivoting Gold Dome tweeter
- Adjustment Controls: HF Level Switch (+3 dB / 0 dB / -3 dB)
- Overall Diameter (Including Grille): 285 mm (11 1/4")
- Overall Depth (Including Grille): 126 mm (4 15/16")
- Mounting Depth: 122 mm (4 13/16")
- Cut-Out Hole Diameter: 247 mm (9 3/4")
- Fixing Type: 3 position Tri-Grip dog fixings
- Optional Square Grille - Outer Dimensions: 285 x 285 mm (11 1/4")
- Construction Material: Mineral filled ABS, RoHS compliant
- Weight: 2.72 kg (6 lb)
- Pre-Construction Bracket: CL-B
- Back Box: CML-BOX
- Sold As: Single Unit with CL-Round Grille (white)
- Warranty: Lifetime
